A new active high-gain external GNSS antenna compatible with GPS, Beidou and GLONASS satellite navigation systems has been officially launched by our company, delivering high-precision positioning solutions for vehicles, agricultural machinery, vessels and IoT positioning equipment.

This triple-mode GNSS antenna is equipped with a built-in 35 dB high-gain LNA amplifier, paired with an antenna gain of 4.5 dBi. Featuring right-hand circular polarization, the device effectively receives signals from three major global satellite constellations, greatly improving positioning accuracy and anti-interference performance in complex outdoor operating environments.

In terms of structural design, the positioning antenna adopts a magnetic mount for quick installation on vehicle roofs and metal equipment surfaces. The standard 3-meter RG174 coaxial cable comes with optional SMA Male or FAKRA-C connectors to match most mainstream navigation modules and tracking terminals. Measuring only 50×50×17 mm with a compact black housing, it achieves a wide operating temperature range of -40℃ to +85℃ and works stably under 0%–95% non-condensing humidity, fully meeting vehicle-mounted, industrial and outdoor application standards.

Compared with single or dual-mode antennas on the market, this triple-mode GPS-Beidou-GLONASS antenna has obvious competitive edges. The multi-system signal reception ensures continuous positioning even in signal-blocked areas such as urban canyons and mountainous regions. Our company supports customized cable lengths and connector types to satisfy differentiated customer demands, with flexible MOQ and stable mass production capacity.
