Item

Specifications

GSM Antenna

Frequency Range

824-960MHz/1710-2170MHz

Polarization

Linear

Gain

2dBi

V.S.W.R

<2.5

Impedance

50ohm

Mechanical

Cable

RG174

Connector

SMA/MCX/FAKRA or others

Radome Material

ABS

Mounting Method

Magnet/Adhesive

Environmental

Operating Temperature

-40+85 degree

Relative Humidity

Up to 95%

Ingress Protection

IP67

Vibration

10 to 55Hz with 1.5mm amplitude 2hours

Environmentally Friendly

ROHS Compliant
