Support of standards protocols

IEEE 802.11n、IEEE 802.11g、IEEE 802.11b、CSMA/CA with ACK

type

USB 1.1/2.0

Frequency range

2.4～2.4835GHz

Transmission rate

11n: 270/243/216/162/108/81/54/27Mbps

135/121.5/108/81/54/40.5/27/13.5Mbps

130/117/104/78/52/39/26/13Mbps；

65/58.5/52/39/26/19.5/13/6.5Mbps

11g：54/48/36/24/18/12/9/6M

11b：11/5.5/2/1M

Channels

14

Lanch receiving type

1T2R

spread-spectrum technique

DSSS

Data Modulation Type

OFDM/CCK/16-QAM/64-QAM

Sensitivity@PER

270M：-68dBm@10% PER；130M： -68dBm@10% PER；

108M：-68dBm@10% PER；54M：-68dBm@10% PER

11M：-85dBm@8% PER；6M：-88dBm@10% PER

1M：-90dBm@8% PER

RFPower

20dBm（max）

Gain

2dBi Separate antenna, can be arbitrary replacement

LED

Status

Dimension

100*26*12.2mm

Environment

Working temperature：0℃ to 40℃

Storage Temperature：-40℃ to 70℃

Working Humidity：10% to 90%RH noncondensing

Humidity Storage：5%to 90%RH noncondensing

OS Support

Windows XP/VISTA/WIN 7/LINUX/MAC OS
